DS2Y-SL2-DC5V 5VDC Relay DPDT Panasonic Latched 20x10mm DIP-10

Original price was: ₨ 400.Current price is: ₨ 375.

Compare
Add to wishlist
Category:
Description

Product details of DS2Y-SL2-DC5V 5VDC Relay DPDT Panasonic Latched 20x10mm DIP-10
DS2Y-SL2-DC5V 5VDC Relay DPDT Panasonic 20x10mm DIP-10 is dual coil Relay.

Specification of DS2Y-SL2-DC5V 5VDC Relay DPDT Panasonic Latched 20x10mm DIP-10
Contact Configuration: DPDT (Double Pole Double Throw)
Dimensions (LxWxH): 20 x 10 x 10mm
Operating Function: 2 coil latching type (L2)
Package: DIP-10
Mounting Type: PCB Mount
Terminal Type: Through Hole
Application: General Purpose
Arrangement: 2 Form c
Max Switching Voltage: 2A, 30VDC
Switching Current: 170mA
Maximum Current: 1A
Coil voltage: 5VDC
Power Consumption: 200mW
Ambient Temperature: -40 to +85 °C
