The LM2576T-ADJ is a monolithic IC that provides all the active functions for a step-down (buck) switching regulator. 2576T ADJ is capable of driving a 3-A load with excellent line and load regulation. The LM2576T-ADJ is available in an adjustable output version, which allows you to set the output voltage to any value between 1.2 and 30 V.
The LM2576T-ADJ is a high-efficiency Step−Down Switching Regulator (Buck Converter) , with typical efficiency of up to 90%. LM2576T ADJ IC also features TTL shutdown capability, which allows you to turn off the regulator by applying a low logic level to the SHUTDOWN pin.
The maximum output voltage is limited by the input voltage and the internal circuitry of the LM2576T-ADJ. The maximum input voltage is 40 V, so the maximum output voltage is 37 V.
The minimum output voltage is limited by the ADJ pin voltage and the RSET resistor. The minimum ADJ pin voltage is 1.23 V, so the minimum output voltage is 1.23 V + 1.23 V = 2.46 V.
The LM2576T-ADJ is an adjustable output voltage regulator IC, which means that you can set the output voltage to any value between 1.2 and 30 V. The output voltage is set by the feedback network, which consists of the ADJ pin, the RSET resistor, and the CADJ capacitor.
This LM2576 IC is a switching regulator, which means that it uses a switching circuit to convert the input voltage to the output voltage. This is in contrast to a linear regulator, which uses a series resistor to drop the input voltage to the output voltage.
Features : –
The LM2576T-ADJ is a versatile and efficient voltage regulator that can use in a wide variety of applications. The adjustable output voltage makes it a good choice for applications where the output voltage needs to be precisely controlled. The LM2576T ADJ is a versatile and efficient voltage regulator that offers a number of benefits, including
High efficiency
Adjustable output voltage
TTL shutdown capability
Simple to use
Inexpensive
Small size
Wide operating temperature range
Robust design
